CNC (Computer Numerical Control) machining parts fixtures are specialized tools or devices used in conjunction with CNC machines to hold and position workpieces during the machining process. Fixtures are essential in CNC machining as they ensure accurate and repeatable production by securely holding the workpiece in place, preventing movement or vibration that could affect the precision of the machining operation.

Fixtures used in CNC machining are typically custom-designed and manufactured to suit the specific dimensions and requirements of the workpiece being machined. They can vary widely in complexity, from simple clamps and vises to more intricate modular or dedicated fixtures.

Here are some common types of fixtures used in CNC machining:

1. Vises: Vises are versatile and commonly used fixtures that hold the workpiece firmly in place using movable jaws. They allow for secure clamping and easy adjustment of the workpiece.

2. Clamps: Clamps are used to hold workpieces against a fixed surface or another part of the fixture. They come in various forms, including toggle clamps, screw clamps, and pneumatic clamps.

3. Jigs: Jigs are fixtures that guide the cutting tool during machining operations. They often have pre-defined holes, slots, or guides to ensure precise and accurate tool positioning.

4. Fixturing Plates: Fixturing plates are flat surfaces with a grid of mounting holes. They allow for the attachment and positioning of custom-designed fixtures or workholding components.

5. Modular Fixtures: Modular fixtures consist of standardized components that can be rearranged or combined to create a fixture suitable for different workpieces. They offer flexibility and reusability.

6. Dedicated Fixtures: Dedicated fixtures are specifically designed for a particular workpiece or part. They are often used for high-volume production to ensure consistent positioning and accuracy.

The selection and design of fixtures depend on factors such as the shape, size, and complexity of the workpiece, as well as the machining operations required. Skilled machinists or engineers typically design fixtures based on the specific requirements of the CNC machining project.

It's worth noting that the actual design and construction of fixtures may vary depending on the specific needs and capabilities of the CNC machining equipment and the expertise of the manufacturing facility or machinist.
